Main Dimensions & Performance Data
| d | 60 mm | Bore diameter |
| D | 130 mm | Outside diameter |
| B | 31 mm | Width |
| Cr | 89,000 N | Basic dynamic load rating, radial |
| C0r | 52,000 N | Basic static load rating, radial |
| Cur | 3,600 N | Fatigue load limit, radial |
| nG | 7,900 1/min | Limiting speed |
| nϑr | 7,400 1/min | Reference speed |
| ≈m | 1.68 kg | Weight |
Mounting dimensions
| da min | 72 mm | Minimum diameter shaft shoulder |
| Da max | 118 mm | Maximum diameter of housing shoulder |
| ra max | 2.1 mm | Maximum fillet radius |
Dimensions
| rmin | 2.1 mm | Minimum chamfer dimension |
| D1 | 109.02 mm | Shoulder diameter outer ring |
| D2 | 112.14 mm | Caliber diameter outer ring |
| d2 | 79.58 mm | Caliber diameter inner ring |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 150 °C | Operating temperature max. |
Calculation factors
| f0 | 13.2 | Calculation factor |
Your current product variant
| Design, bearing outer ring | N | Ring groove for snap ring |
| Changed internal design | C | GenerationC |
| Sealing | without | not sealed |
| Cage | JN | steel sheet metal |
| Tolerance class | P6 | Class6 (P6), better than PN |
| Dimensional / heat stabilization | S0 | Rings dimensional stabilized up to 150° |
| Lubricant | without | Bearing not greased |
| Radial internal clearance | CN | Group N (CN) |
| Bore type | Z | Cylindrical |
